CCL1301820MPF67
Fisheye 5-Megapixel M12 lens with Built-In IR Filter, for 1/3″ sensors, 200° FOV at 4.7mm, F2.0 aperture, and IP67 waterproof rating.
CCL1301820MPF67 is Fisheye 5-Megapixel M12 lens with Built-In IR Filter, for 1/3″ sensors, 200° FOV at 4.7mm, F2.0 aperture, and IP67 waterproof rating.
| IMAGE FORMAT | 1/3″ Φ4.7mm |
| FOCAL LENGTH | 1.8mm |
| F.O.V.@4.7mm | 200° |
| F.O.V.@4.6mm | 185° |
| F.O.V.@3.4mm | 110° |
| RESOLUTION | 5 Megapixel |
| DISTORTION | <-119% |
| APERTURE | F2.0 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.3m |
| T.T.L. | 14mm |
| B.F.L. | 3.46mm |
| COMPONENT | 6G+IRCF |
| WATERPROOF | IP67 |
