Fisheye CCTV HD lens 1/2″ Φ4.7 185° M12 mount lens 5MP F2.0 security surveillance lens
CCL12014MP Fisheye CCTV HD lens 1/2″ Φ4.7 185° M12 mount lens 5MP F2.0 security surveillance lens
| IMAGE FORMAT | 1/2″ Φ4.7 |
| FOCAL LENGTH | 1.4mm |
| F.O.V. | 185°(D) |
| 185°(H) | |
| 185° (V) | |
| RESOLUTION | 5 MP |
| F-θ DISTORTION | <-3.7% |
| APERTURE | F2.0 |
| MOUNT | M12X0.5 |
| IRIS | Fixed |
| FOCUS | Manual |
| ZOOM | Fixed |
| B.F.L. | 2.55mm |
| TTL | 16.65 |
| LENS COMPOMEMT | 4G2P |
CCL12014MP Fisheye CCTV HD lens Φ4.7 185° M12 mount lens 5MP F2.0 security surveillance lens
Online contact
| SENSOR | |
|---|---|
| E.F.L. | |
| H. F.O.V. | |
| FNo. | |
| Max Dist. | |
| IRIS | |
| MOUNT | |
| RESOLUTION | |
| T.T.L.(mm) | |
| FEATURE | |
| MARK |
