CCL130368MPF
3.68mm Wide-angle CCTV lens with IR cut, 1/3″ M12/S-mount lens, F2.4 107° 3MP resolution, security surveillance lens.
CCL130368MPF is 3.68mm Wide-angle CCTV lens with IR cut, 1/3″ High Magnification M12/S-mount lens, F2.4 107° 3MP resolution, security surveillance lens.
| IMAGE FORMAT | 1/3″ |
| FOCAL LENGTH | 3.68mm |
| F.O.V.(@AR0330) | 107°(D) |
| 85°(H) | |
| 54°(V) | |
| DISTORTION | -25% |
| RESOLUTION | 3MegaPixel |
| APERTURE | F2.4 |
| MOUNT | M12X0.5 |
| IRIS | Fixed |
| FOCUS | Manual |
| ZOOM | Fixed |
| B.F.L. | 6.18mm |
| C.R.A. | <21° |
| R.I. | >80% |
| M.O.D. | 0.3m |
| CONSTRUCTION | 5G+IR cut |
