CCL127037MPF
3.7mm F2.0 Wide-angle CCTV 2-Megapixel lens IR cut 1/2.7″ 120° M12/S-mount lens security surveillance lens
CCL127037MPF-High-Resolution Wide-angle CCTV 2-Megapixel lens IR cut 1/2.7″ 120° Low F-number M12/S-mount lens (F2.0) security surveillance lens.
| IMAGE FORMAT | 1/2.7″ |
| FOCAL LENGTH | 3.7mm |
| F.O.V.(OV2710) | 120°(D) |
| 97°(H) | |
| 52°(V) | |
| DISTORTION | -28% |
| RESOLUTION | 2 MP |
| APERTURE | F2.0 |
| MOUNT | M12X0.5 |
| IRIS | Fixed |
| FOCUS | Manual |
| ZOOM | Fixed |
| B.F.L. | 5.48mm |
| M.O.D. | 0.3m |
| CONSTRUCTION | 6G+IR cut |
