Fisheye Lens – CCL14015MPF

CCL14015MPF is 1/4″ 1.5mm Fisheye lens with Built-In Filter, Low F-number S-Mount Lens (F2.0), high resolution 16-Megapixel Wide Angle Lens.

M12 1.5mm 16MP Fisheye Lens

This 1.5mm M12 fisheye lens delivers an ultra-wide 180° diagonal field of view with 16MP resolution, making it ideal for compact cameras that require maximum scene coverage from a very small form factor. With an M12×0.5 mount, F2.0 fixed aperture, and integrated 850nm filter, it is designed for panoramic machine vision, robotics, smart security, and embedded imaging systems.

M12 Fisheye Lens Core Highlights

• 180° diagonal ultra-wide FOV for maximum scene coverage from a compact lens.
• 16MP resolution supports high-detail imaging for advanced embedded vision systems.
• 1.5mm focal length enables extremely wide-angle panoramic image capture.
• M12×0.5 compact mount simplifies integration into small camera modules and vision devices.
• Integrated 850nm filter supports imaging configurations requiring controlled near-infrared spectral transmission.

Applications & Compatible Devices

Core Application Scenes

The extreme field of view of this 1.5mm M12 fisheye lens makes it particularly suitable for applications where a conventional wide-angle lens cannot provide sufficient scene coverage. Its 180° diagonal FOV allows a compact camera to capture a broad surrounding area while maintaining a short optical path, making it valuable for embedded imaging systems with strict space limitations.

For robotics vision, the lens can be integrated into compact mobile robots, autonomous platforms, and robotic perception modules where a wide viewing angle helps detect nearby objects and monitor the surrounding environment. The short 1.5mm focal length is especially useful when the camera needs to observe a large area at relatively close working distances.

In smart security, this fisheye configuration can be used for compact indoor surveillance cameras, ceiling-mounted monitoring modules, and embedded security devices that require broad coverage from a single camera. The 16MP optical capability provides additional image detail for systems that need to inspect a wide scene.

The lens is also suitable for panoramic embedded cameras, industrial inspection modules, smart IoT devices, and specialized machine vision systems where compact mechanical dimensions and ultra-wide coverage are more important than conventional low-distortion imaging.

Designed for ultra-wide panoramic machine vision and compact embedded imaging applications.

Compatible Device List

• Embedded Vision Cameras: Suitable for compact camera modules using 1/4″ image sensors and M12×0.5 lens interfaces.
• Robotics & Mobile Platforms: Well suited to mobile robots, autonomous platforms, and robotic perception modules requiring broad environmental awareness.
• Smart Security Cameras: Applicable to compact panoramic surveillance cameras, indoor monitoring devices, and wide-area security modules.
• Industrial Vision Systems: Can be integrated into specialized machine vision equipment where extremely wide scene coverage is required.
• Panoramic & IoT Imaging Devices: Suitable for compact panoramic cameras, smart IoT vision devices, and other embedded imaging products.
• Customized Camera Modules: The M12 mechanical format makes the lens suitable for OEM/ODM camera designs requiring a compact optical assembly.

For systems requiring help selecting the appropriate sensor and optical configuration, the lens selection guide and sensor guide can be used during the initial design stage. Field-of-view requirements can also be evaluated with the FOV calculator, particularly when determining how much of a nearby scene can be captured with an ultra-wide lens.

Frequently Asked Questions

• Q: What type of lens is this?
  A: This is a fixed-focal-length M12 fisheye lens with a 1.5mm focal length and an ultra-wide 180° diagonal field of view.
• Q: What is the field of view of this 1.5mm lens?
  A: The specified field of view is 180° diagonal, 141° horizontal, and 85° vertical, providing extremely broad scene coverage.
• Q: What sensor size is this lens designed for?
  A: The lens is specified for a 1/4″ image format and should be matched with a compatible 1/4″ sensor during camera system design.
• Q: Is this lens suitable for machine vision applications?
  A: Yes. Its ultra-wide FOV, 16MP resolution, and compact M12 mount make it suitable for specialized machine vision applications requiring broad scene coverage.
• Q: Is the aperture adjustable?
  A: No. The lens uses a fixed F2.0 aperture, providing a consistent optical configuration for compact embedded camera systems.
• Q: What is the minimum object distance?
  A: The specified minimum object distance is 0.2m, making the lens suitable for relatively close-range ultra-wide imaging applications.
• Q: What is the function of the 850nm filter?
  A: The integrated 850nm filter provides controlled spectral filtering around the near-infrared wavelength range and can be useful in camera systems designed around specific NIR illumination or imaging requirements.
• Q: Can this M12 fisheye lens be customized for OEM projects?
  A: M12 optical assemblies can be adapted for specific OEM/ODM requirements depending on the mechanical, optical, sensor, and spectral requirements of the project. For a customized configuration, contact the TOWIN engineering team.
