CCL130165MPF
Fisheye CCTV HD lens IR corrected 1/3″ Φ3.5 M12 lens 184° 3MP F2.2 security surveillance
CCL130165MPF Fisheye CCTV HD lens IR corrected 1/3″ Φ3.5 M12 lens 184° 3MP F2.2 security surveillance
| IMAGE FORMAT | Φ3.5, 1/3″ |
| FOCAL LENGTH | 1.65mm |
| F.O.V.(1/3″) | 184°(D) |
| 184°(H) | |
| 184°(V) | |
| RESOLUTION | 3Megapixel |
| DISTORTION | <-100% |
| APERTURE | F2.2 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.2m |
| T.T.L. | 23.7mm |
| M. B.F.L. | 4.45mm |
| IR cut filter | Yes |
CCL130165MPF Fisheye CCTV HD lens IR corrected Φ3.5 M12 lens 184° 3MP F2.2 security surveillance
