CCL128021MPR
HD CCTV wide angle 2.1mm M12 S-mount board lens F2.0 tailor distortion surveillance
CCL128021MPR HD CCTV wide angle 2.1mm M12 S-mount board lens F2.0 tailor distortion surveillance
| IMAGE FORMAT | 1/2.8″ |
| FOCAL LENGTH | 2.1mm |
| F.O.V. | 160°(D) |
| 135°(H) | |
| 88°(V) | |
| RESOLUTION | Megapixel |
| OPTICAL DISTORTION | -59% |
| APERTURE | F2.0 |
| MOUNT | M12X0.5 |
| IRIS | Fixed |
| FOCUS | Manual |
| ZOOM | Fixed |
| B.F.L. | 5.13mm |
| TTL | 25.16 |
| M.O.D. | 0.2m |
| LENS COMPOMEMT | 6G |
CCL128021MPR HD CCTV wide angle 2.1mm M12 S-mount board lens F2.0 tailor distortion surveillance
