CCL12703616MP
Low light F1.6 HD CCTV M12 S-mount board lens wide angle 3.6mm 2MP OV2710
CCL12703616MP Low light F1.6 HD CCTV M12 S-mount board lens wide angle 3.6mm 2MP OV2710
| IMAGE FORMAT | 1/2.7″ |
| FOCAL LENGTH | 3.6mm |
| F.O.V. | 114°(D) |
| 96°(H) | |
| 58°(V) | |
| RESOLUTION | 2 Megapixel |
| APERTURE | F1.6 |
| MOUNT | M12X0.5 |
| IRIS | Fixed |
| FOCUS | Manual |
| ZOOM | Fixed |
| B.F.L. | 5.2mm |
| TTL | 22.7 |
| M.O.D. | 0.2m |
| LENS COMPOMEMT | 6G |
| IR | Corrected |
CCL12703616MP Low light F1.6 HD CCTV M12 S-mount board lens wide angle 3.6mm 2MP OV2710
