Low Distortion Lens – S12012702616

S12012702616 is 12mm High-resolution low-distortion lens, 1/2.7″ Low F-number M12/S mount lenses, F1.6 aperture 5 Megapixel CCTV HD lens.

1/2.7″ Low Distortion Lens

This 12mm F1.6 M12 lens is a high-resolution fixed focal lens designed for 1/2.7″ sensors, delivering 5MP imaging with less than -2.5% distortion. Its narrow 26° horizontal field of view and controlled optical distortion make it suitable for compact imaging systems that require accurate scene reproduction and focused target coverage.

Product Highlights at a Glance

• < -2.5% distortion supports more accurate image geometry.
• 12mm focal length provides focused target coverage for longer-distance imaging setups.
• 5MP resolution delivers detailed images for high-definition compact vision systems.
• F1.6 aperture provides strong light-gathering capability for variable-light environments.
• M12×0.5 mount enables integration into compact camera and embedded vision modules.

Low Distortion Lens Applications

Core Application Scenes

This 12mm M12 low distortion lens is designed for imaging applications where controlled perspective and accurate image geometry are more important than extremely wide scene coverage. Its 26° horizontal FOV provides a relatively focused view, while the specified distortion of less than -2.5% helps reduce geometric deformation across the image.

The lens is particularly suitable for compact vision systems that need to observe a defined target area from a moderate working distance. Potential applications include dimensional observation, component inspection, barcode and code imaging, equipment monitoring, and embedded camera systems where excessive barrel or pincushion distortion could affect image interpretation.

The 5MP optical specification provides sufficient image detail for high-resolution compact imaging platforms. Combined with the 12mm focal length, it can help system designers concentrate pixels on a specific inspection or monitoring area rather than distributing the available resolution across an excessively wide scene.

The F1.6 aperture further supports applications where illumination is not completely uniform. It provides useful light-gathering capability while maintaining a compact M12 form factor. The 0.2m minimum object distance also gives designers flexibility when the camera needs to be positioned relatively close to the target.

For systems where image geometry is important, the Distortion Guide provides additional information about lens distortion and its influence on imaging results. Engineers can also review the Lens Selection Guide when comparing focal length, sensor format, FOV, and distortion requirements.

Designed for compact low-distortion inspection, measurement, and embedded vision applications.

Compatible Device List

• 1/2.7″ CMOS Camera Modules: Designed for camera systems using 1/2.7″ sensors and requiring up to 5MP optical resolution.
• Compact Machine Vision Cameras: Suitable for embedded inspection systems requiring controlled target framing and reduced geometric distortion.
• Measurement Imaging Devices: The low-distortion optical design can support applications where image geometry is an important consideration.
• Barcode & Code Reading Cameras: The 12mm focal length and relatively narrow FOV can concentrate image detail on a defined reading area.
• Equipment Monitoring Cameras: Suitable for monitoring specific components, instruments, or machinery rather than large panoramic scenes.
• OEM Embedded Vision Systems: The M12×0.5 mount allows integration into compact camera housings and customized imaging equipment.

For additional compact lens options, explore M12 Lenses. For machine vision system integration, see Machine Vision Solutions.

When selecting the required focal length for a specific working distance and target size, the Focal Length Calculator can help engineers determine an appropriate focal-length starting point.

Frequently Asked Questions

Q: What sensor size is this 12mm M12 lens designed for?
A: This lens is designed for 1/2.7″ image sensors and supports 5 Megapixel imaging applications.

Q: What is the field of view of the 12mm M12 lens?
A: The specified field of view is 30° diagonal, 26° horizontal, and 15° vertical.

Q: How low is the distortion of this lens?
A: The specified distortion is less than -2.5%, making the lens suitable for applications where controlled image geometry is important.

Q: Is this lens suitable for machine vision applications?
A: Its 5MP resolution, 12mm focal length, controlled FOV, and low-distortion specification make it suitable for certain compact machine vision and inspection applications. Final suitability should be evaluated according to the sensor, working distance, target size, and required accuracy.

Q: What is the advantage of the 12mm focal length?
A: The 12mm focal length provides a relatively narrow viewing angle, allowing the camera to concentrate imaging coverage on a defined target area rather than capturing an excessively wide scene.

Q: What does the F1.6 aperture provide?
A: F1.6 provides good light-gathering capability, which can help maintain image brightness in applications with moderate or changing illumination.

Q: What is the minimum object distance of this lens?
A: The minimum object distance is 0.2m, allowing the lens to focus on relatively close targets.

Q: What mount does this lens use?
A: The lens uses an M12×0.5 mount, which is commonly used in compact camera modules, embedded vision equipment, and small-form-factor imaging systems.
