Low Distortion Lens – S07212004925

S07212004925 is 5-Megapixel low distortion 1/2″ M12/S-Mount CCTV lens, 58.5°(D) F2.5 with 0.1m MOD for machine vision and security surveillance.

7.2mm 5MP M12 Low Distortion Lens

This 7.2mm M12 Low Distortion Lens is a 5MP fixed focal lens designed for 1/2″ image sensors, providing a 58.5° diagonal field of view with less than -1.4% distortion. Its F2.5 aperture, 0.1m minimum object distance, and compact M12x0.5 mount make it suitable for industrial cameras, inspection systems, smart devices, and compact machine vision equipment where consistent imaging and controlled distortion are required.

Product Highlights at a Glance

• 7.2mm fixed focal length for stable and repeatable image capture
• 5MP resolution for detailed imaging on 1/2″ sensors
• Low distortion < -1.4% for applications requiring controlled geometric accuracy
• F2.5 aperture provides a practical balance between light transmission and compact optical design
• M12x0.5 mount enables easy integration into compact camera systems

7.2mm M12 Low Distortion Lens Applications

Core Application Scenes

This 7.2mm M12 lens is designed for imaging systems that need a moderate field of view without the strong geometric distortion associated with ultra-wide optical designs. The 58.5° diagonal FOV provides useful scene coverage for compact inspection and recognition systems, while the < -1.4% distortion specification helps maintain relatively accurate object geometry across the image.

With a 0.1m minimum object distance, the lens can also be integrated into relatively close-range imaging setups where the camera needs to capture objects without requiring a long working distance. The F2.5 fixed aperture provides a consistent optical configuration for embedded cameras and automated equipment.

For systems requiring more detailed optical matching, users can review the Lens Selection Guide or use the FOV Calculator to evaluate focal length and field-of-view requirements.

Compatible Device List

• 1/2″ industrial cameras
• Compact machine vision cameras
• Embedded inspection cameras
• Smart recognition cameras
• Fixed-focus vision modules
• Compact automation imaging equipment
• Close-range inspection systems
• Space-constrained camera assemblies

Designed for compact industrial imaging and machine vision application where 5MP resolution, moderate FOV, and controlled distortion are required.

Frequently Asked Questions

Q: What sensor size is compatible with this 7.2mm M12 lens?
A: This lens is designed for 1/2″ image formats and provides a 58.5° diagonal, 49° horizontal, and 37° vertical field of view.

Q: Is this a low distortion lens?
A: Yes. The specified distortion is less than -1.4%, making it suitable for imaging applications where geometric distortion needs to be controlled.

Q: Is the 7.2mm focal length fixed or adjustable?
A: It is a fixed focal lens with a 7.2mm focal length and fixed iris.

Q: What type of mount does this lens use?
A: The lens uses an M12x0.5 mount, a compact threaded interface commonly used in embedded cameras and small vision systems.

Q: What is the minimum object distance of this M12 lens?
A: The minimum object distance is 0.1m, allowing the lens to support relatively close-range imaging applications.

Q: What resolution does the lens support?
A: The lens is specified for 5MP imaging and is designed for use with 1/2″ image sensors.

Q: Is this lens suitable for machine vision applications?
A: It can be used in compact machine vision and inspection systems that require a fixed 7.2mm focal length, moderate field of view, and controlled distortion. Final suitability should be confirmed based on the camera sensor, working distance, and required field of view.

Q: How can I determine whether this lens provides enough field of view for my application?
A: You can compare the 58.5° diagonal FOV with your target scene size and working distance. TOWIN’s FOV Calculator can help estimate the required focal length for a specific setup.
