M806312504852
CCTV lens 1/2.5″ & 1/2.7″ 6.3mm lens, M8x0.35 mount lens, 5-Megapixel Ultra-low distortion lens, F5.2.
M806312504852 is CCTV lens 1/2.5″ & 1/2.7″ 6.3mm lens, High-resolution M8x0.35 mount lens, 5-Megapixel Ultra-low distortion lens, F5.2 Aperture.
| IMAGE FORMAT | 1/2.5″, 1/2.7″ |
| FOCAL LENGTH | 6.3mm |
| F.O.V.@1/2.5″ | 59°(D=7.12) |
| 48°(H=5.70) | |
| 37°(V=4.28) | |
| F.O.V.@1/2.7″ | 55°(D=6.61) |
| 49°(H=5.76) | |
| 28°(V=3.24) | |
| RESOLUTION | 5MP |
| TV DISTORTION | <-0.4% |
| APERTURE | F5.2 |
| MOUNT | M8x0.35 |
| M.O.D. | 0.2m |
| T.T.L. | 10.51mm |
| STRUCTURE | Without IRCF |
