D14351011820F6S
3.5-10mm motorized zoom CCTV lens, 1/1.8″ D14 mount, fixed iris F2.0, 6-Megapixel, adjustable wide-angle field of view, IR corrected.
D14351011820F6S is 3.5-10mm motorized zoom CCTV lens, 1/1.8″ D14 mount, fixed iris F2.0, 6-Megapixel High resolution, adjustable wide-angle field of view, IR corrected.
| IMAGE FORMAT | 1/1.8″ |
| FOCAL LENGTH | 3.5-10mm |
| H F.O.V.@1/1.8″ | 117°~42° |
| H F.O.V.@1/2.5″ | 90°~35° |
| RESOLUTION | 6MP |
| APERTURE | F2.0 |
| DISTORTION@1/2.5″ | <-47%(3.5mm) |
| DISTORTION@1/2.5″ | <-6%(10mm) |
| MOUNT | D14 |
| B.F.L. | 7.5mm |
| IRIS | Fixed |
| FOCUS | Motorized |
| ZOOM | Motorized |
| M.O.D. | 0.3m |
| IR | Corrected |
