CCTV Lens – CS125011716M5

CS125011716M5 is 5-Megapixel IR correction CCTV lens, 1/1.7″ 12-50mm manual iris, focus, and zoom lens, low distortion lens, F1.6 aperture CS mount lens.

12-50mm 5MP CS-Mount IR Corrected Zoom Lens

This 12-50mm 5MP CS-Mount zoom lens is designed for professional surveillance cameras that require flexible field-of-view adjustment across different monitoring distances. With a 1/1.7″ image format, F1.6 aperture, manual zoom and focus, and IR-corrected optical performance, it provides a practical solution for high-resolution CCTV and intelligent security imaging.

CS-Mount CCTV Lens Core Highlights

• 12–50mm manual zoom provides flexible framing from wider monitoring areas to long-distance subjects.
• 5MP resolution supports detailed surveillance imaging with a 1/1.7″ sensor.
• F1.6 aperture helps maintain image brightness in challenging lighting environments.
• IR-corrected optical design supports consistent focus performance across visible and near-infrared imaging.
• CS-Mount configuration integrates easily with compatible professional CCTV camera systems.

CS-Mount CCTV Lens Applications

Core Application Scenes

This 12-50mm CS-Mount zoom lens is developed for surveillance systems where the camera needs to cover different distances without replacing the optical assembly. Its 12mm wide-end focal length provides a relatively broad monitoring view, while the 50mm telephoto end allows operators to obtain a narrower view of distant subjects.

For professional security installations, the manual zoom structure allows the installer to adjust the field of view according to the actual camera position and surveillance area. This makes the lens suitable for entrances, building perimeters, industrial sites, parking areas, warehouse corridors, and other locations where the monitoring distance can vary considerably.

The F1.6 maximum aperture is beneficial for surveillance cameras operating under changing illumination. Combined with IR correction, the lens can support imaging systems that use visible light during the day and near-infrared illumination for nighttime monitoring.

For projects requiring different focal lengths, sensor formats, or optical characteristics, the lens can also be evaluated alongside other CS-Mount Lenses and professional surveillance optics.

Compatible Device List

• Professional CCTV Cameras: Suitable for CS-Mount surveillance cameras using 1/1.7″ sensors and requiring 5MP optical resolution.
• Fixed Security Installations: Appropriate for building entrances, perimeter monitoring, warehouses, parking areas, and industrial facilities where the viewing distance varies.
• Day/Night Surveillance Systems: The IR-corrected design supports camera systems using visible and near-infrared illumination.
• Manual-Adjustment Camera Systems: Manual iris, focus, and zoom provide installers with direct optical adjustment during system setup.
• Intelligent Security Equipment: Can be integrated into high-resolution network surveillance and AI-assisted video monitoring systems.
• Custom Optical Projects: Towin can evaluate customized focal lengths, coatings, mechanical configurations, and other optical requirements for OEM/ODM projects.

Designed for professional CCTV surveillance, variable-distance security monitoring, and IR-assisted day/night imaging applications.

For applications involving changing monitoring distances, our Smart Security solutions provide additional guidance on selecting suitable optical components for surveillance systems.

When choosing a lens for a specific sensor and monitoring distance, the Lens Selection Guide can help engineers evaluate focal length, sensor format, field of view, and other optical parameters.

You can also use the FOV Calculator to estimate the relationship between sensor size, focal length, and field of view before selecting the final lens configuration.

Frequently Asked Questions

Q: What type of camera is this 12-50mm lens designed for?
A: This lens is designed primarily for professional CCTV and security cameras with a CS-Mount interface and a 1/1.7″ image sensor.

Q: Is this a fixed focal length lens?
A: No. The lens provides a 12–50mm focal length range with manual zoom, allowing the user to adjust the viewing angle according to the monitoring distance.

Q: What resolution does this CS-Mount zoom lens support?
A: The lens is specified for 5 Megapixel imaging and is designed for applications requiring detailed surveillance images.

Q: What is the advantage of the IR-corrected optical design?
A: IR correction helps maintain more consistent optical focus when a camera operates across visible and near-infrared wavelengths, which is useful for day/night surveillance systems.

Q: What field of view can this lens provide?
A: The diagonal FOV ranges from 46° at the 12mm wide end to 11° at the 50mm telephoto end. The horizontal FOV ranges from 36° to 9°, while the vertical FOV ranges from 27° to 6.5°.

Q: Can the iris, focus, and zoom be adjusted manually?
A: Yes. The lens uses manual iris, manual focus, and manual zoom mechanisms, giving installers direct control during camera installation and optical calibration.

Q: What is the minimum object distance of this lens?
A: The specified minimum object distance is 1.5 meters.

Q: Can Towin provide customized versions of this lens?
A: Towin can evaluate customized optical and mechanical requirements for OEM/ODM projects, including application-specific configurations, coatings, and mechanical interfaces. For project requirements, contact our optical engineering team for further evaluation.
