CCL23050MMPCR
CCTV 2/3″ 5mm C-mount wide-angle lens, 5-Megapixel low-distortion manual iris lens.
CCL23050MMPCR is CCTV 2/3″ 5mm C-mount wide-angle lens, 5-Megapixel low-distortion manual iris lens, designed for high-resolution machine vision applications.
| IMAGE FORMAT | 2/3″ |
| FOCAL LENGTH | 5mm |
| F.O.V. | 95°(D) |
| 82°(H) | |
| 67°(V) | |
| RESOLUTION | 5 MP |
| APERTURE | F1.6~C |
| DISTORTION | <2.8% |
| MOUNT | C |
| B.F.L. | 14.50mm |
| IRIS | Manual |
| FOCUS | Manual |
| ZOOM | Manual |
| M.O.D. | 0.1m |
| With 850nm band pass filter |
