CS1212312F8
8 Megapixel CCTV HD lens, F1.2 CS mount lens, low light sensitive lens, IR corrected.
CS1212312F8 is 8 Megapixel CCTV HD lens, F1.2 CS mount lens with Low F-number (Fast Lenses), High-resolution low light sensitive lens, IR corrected.
| IMAGE FORMAT | 1/2.3″, 1/2.7″ |
| FOCAL LENGTH | 12mm |
| F.O.V.@1/2.3″ | 40°(D) |
| 31°(H) | |
| 23° (V) | |
| F.O.V.@1/2.7″ | 33°(D) |
| 29°(H) | |
| 16° (V) | |
| RESOLUTION | 8MP |
| APERTURE | F1.2 |
| MOUNT | CS |
| IRIS | Fixed |
| FOCUS | Manual |
| ZOOM | Fixed |
| M.O.D. | 0.3m |
| IR | Corrected |
