CCL118018MP
Fisheye CCTV HD lens IR corrected 1/1.8″ Φ5.4 M12 lens 185° 3MP F2.8 security surveillance
CCL118018MP Fisheye CCTV HD lens IR corrected 1/1.8″ Φ5.4 M12 lens 185° 3MP F2.8 security surveillance
| IMAGE FORMAT | Φ5.4, 1/1.8″ |
| FOCAL LENGTH | 1.8mm |
| F.O.V.@5.7mm | 185°(H) |
| F.O.V.@3.6mm | 148°(V) |
| RESOLUTION | 3 Megapixel |
| DISTORTION | -94% |
| APERTURE | F2.8 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.1m |
| T.T.L. | 25.8mm |
| STRUCTURE | 6G |
CCL118018MP Fisheye CCTV HD lens IR corrected Φ5.4 M12 lens 185° 3MP F2.8 security surveillance
