S03011813918F
8MP 170° Degree Ultra-Wide Angle Lens, F1.8 Aperture, M12 Mount Lens, Suitable for CCTV Applications.
S03011813918F-8MP 170° Degree Ultra-Wide Angle Lens, F1.8 Aperture, M12 Mount Lens, Suitable for CCTV Applications
| IMAGE FORMAT | Max Φ8.8mm |
| FOCAL LENGTH | 3.0mm |
| F.O.V. (1/1.8″, IMX185) | 170°(D=8.62) |
| 139°(H=7.29) | |
| 84°(V=4.60) | |
| RESOLUTION | 8 MP |
| F.O.V. (1/2.7″, OV2710) | 124°(D=6.61) |
| 106°(H=5.76) | |
| 60°(V=3.24) | |
| DISTORTION | <-78% |
| APERTURE | F1.8 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.2m |
| T.T.L. | 23.4mm |
| STRUCTURE | 6G+IRCF |
