S02612513120F
Wide-angle 5-Megapixel 1/2.5″ Φ7.5 M12 lens with Built-In IR Filter, 160° field of view, F2.0 aperture, for security surveillance.
S02612513120F is Wide-angle 5-Megapixel 1/2.5″ Φ7.5 M12 lens with Built-In IR Filter, 160° field of view, F2.0 aperture, for security surveillance.
| IMAGE FORMAT | Max Φ7.5, 1/2.5″ |
| FOCAL LENGTH | 2.6mm |
| F.O.V. (1/2.5″) | 160° (D=7.12) |
| 131° (H=5.70) | |
| 95° (D=4.28) | |
| RESOLUTION | 5 MP |
| TV DISTORTION | <-29% |
| APERTURE | F2.0 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.2m |
| T.T.L. | 22.05mm |
| STRUCTURE | With IRCF |
