Wide Angle Lens – S01314012225F69

S01314012225F69 is Wide-angle 1/4″ M12-mount 2-Megapixel lens with Built-In IR Filter, F2.5 aperture, and IP69K waterproof rating for -40°C~+85°C operating conditions.

1.3mm M12 Wide Angle Automotive Lens for 2MP Vehicle Cameras

This 1.3mm M12 wide angle automotive lens is designed for compact vehicle camera systems requiring broad scene coverage and reliable operation in demanding outdoor conditions. With a 134° diagonal FOV on the OV2732 sensor, 2MP resolution, F2.5 aperture, IP69K protection, and a -40°C to +85°C working temperature range, it is suitable for a variety of wide-angle automotive imaging applications.

Product Highlights at a Glance

• 134° diagonal FOV provides broad coverage for vehicle-mounted cameras
• 1.3mm fixed focal length supports compact wide-angle automotive camera designs
• 2MP resolution matches the requirements of compact vehicle imaging systems
• IP69K protection supports exposed automotive camera installations
• -40°C to +85°C working temperature for demanding automotive environments

1.3mm M12 Wide Angle Lens Applications

Core Automotive Applications

The 1.3mm focal length provides a broad viewing angle while maintaining a compact M12 × 0.5 optical interface. Combined with a 0.1m minimum object distance, the lens is suitable for applications where the camera needs to capture both nearby objects and a wide surrounding area.

Designed for wide-angle automotive camera applications, this lens can be integrated into compact vehicle imaging modules where wide coverage, environmental protection, and 2MP image performance are required.

Typical applications include:

• Automotive surround-view cameras for monitoring areas around the vehicle
• Parking assistance cameras for capturing nearby obstacles and vehicle surroundings
• Front-view and rear-view cameras requiring broad scene coverage
• Side-view and corner-view cameras for monitoring areas close to the vehicle
• Vehicle-mounted monitoring cameras using compact M12 optical assemblies
• Commercial vehicle camera systems operating in exposed outdoor environments

The combination of IP69K protection and -40°C to +85°C operation makes the lens suitable for appropriately sealed camera modules exposed to water, dust, temperature changes, and demanding vehicle operating conditions.

For complete vehicle vision applications, the lens can be used as part of TOWIN’s ADAS solutions.

Compatible Devices

The lens is suitable for integration with:

• OV2732-based automotive camera modules
• 1/4″ image sensors
• 2MP vehicle camera systems
• Compact M12 camera assemblies
• Automotive surround-view cameras
• Parking assistance camera modules
• Front, rear, side, and corner-view cameras
• Vehicle-mounted monitoring devices

For other compact automotive optical options, see TOWIN’s M12 lens product range. When comparing alternative sensor formats and focal lengths, the FOV Calculator can help evaluate the resulting viewing angle.

Frequently Asked Questions

Q: What is the field of view of this 1.3mm M12 lens?
A: With the OV2732 sensor, the lens provides a 134° diagonal FOV, 122° horizontal FOV, and 82° vertical FOV.

Q: Is this lens suitable for automotive applications?
A: Yes. It is designed for wide-angle vehicle camera applications including surround-view, parking assistance, front/rear viewing, side-view, and vehicle monitoring.

Q: What sensor is this lens designed for?
A: The specified optical performance is based on the OV2732 sensor with a 1/4″ image format and 2MP resolution.

Q: Is this a fisheye lens?
A: This product is positioned as a wide-angle automotive lens rather than a dedicated fisheye lens. Its 134° diagonal FOV provides broad scene coverage for vehicle imaging.

Q: Does this lens have low distortion?
A: No. The specified distortion is below -25%. The optical design prioritizes wide-angle coverage rather than low geometric distortion.

Q: What mount does this lens use?
A: The lens uses an M12 × 0.5 mount, making it suitable for compact automotive and embedded camera modules.

Q: Can the lens operate in harsh automotive environments?
A: Yes. It has an IP69K waterproof rating and a working temperature range of -40°C to +85°C, supporting demanding exterior vehicle camera applications.

Q: What is the minimum object distance?
A: The minimum object distance is 0.1m, allowing the lens to capture relatively close objects in wide-angle automotive imaging applications.
