S01214013520F67
Wide-angle Megapixel M12 Mount 170°(D) Lens with Built-In IR Filter, IP67 Waterproof Automotive Lens Suitable for security Surveillance.
S01214013520F67 is Wide-angle Megapixel M12 Mount 170°(D) Lens with Built-In IR Filter, IP67 Waterproof Automotive Lens Suitable for security Surveillance.
| IMAGE FORMAT | Max Φ4.9mm |
| FOCAL LENGTH | 1.5mm |
| F.O.V. (1/4″) | 170°(D) |
| 135°(H) | |
| 102° (V) | |
| RESOLUTION | Megapixel |
| TV DISTORTION | <-18% |
| APERTURE | F2.0 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.2m |
| T.T.L. | 14.8mm |
| STRUCTURE | 4G2P+IRCF |
| WATERPROOF | IP67 |
