6 MP F1.8 M12-mount wide-angle CCTV lens (170° DFOV) with IR-corrected 6G optics.
CCL118031MPF-6 MP F1.8 M12-mount wide-angle CCTV lens (170° DFOV) with IR-corrected 6G optics.
| IMAGE FORMAT | 1/1.8“ |
| FOCAL LENGTH | 3.1mm |
| F.O.V.(@IMX185) | 170°(D=8.62) |
| 138°(H=7.29) | |
| 84°(V=4.60) | |
| RESOLUTION | 6 MP |
| OPTICAL DISTORTION | <-78% |
| APERTURE | F1.8 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.1m |
| T.T.L. | 23mm |
| STRUCTURE | 6G+IRCF |
