Low Distortion Lens – S07912304525F-IMX477

S07912304525F-IMX477 is Low distortion M12/S-Mount 12.3-Megapixel 1/2.3″ CCTV lens with Built-In IR Filter, 54° diagonal FOV, F2.5 Suitable for machine vision.

7.9mm 12.3MP M12 Low Distortion Fixed Focal Lens

This 7.9mm 12.3MP M12 low distortion lens is designed for high-resolution compact camera systems that require detailed imaging and controlled geometric distortion at a moderate working distance. Optimized for the 1/2.3″ format and specified with the Sony IMX477 sensor, it provides 54° diagonal, 44° horizontal, and 34° vertical field of view.

With a 7.9mm fixed focal length, F2.5 aperture, < -2.4% distortion, M12×0.5 mount, and 9G+IRCF optical construction, this lens is well suited to high-resolution embedded vision, smart monitoring, robotic cameras, and other compact imaging systems requiring precise and detailed scene capture.

Product Highlights at a Glance

• 12.3MP high-resolution imaging captures fine image details for demanding compact vision systems.
• Sony IMX477 compatibility provides a defined sensor platform for high-resolution camera development.
• < -2.4% distortion helps maintain controlled image geometry across the captured scene.
• F2.5 fixed aperture provides a practical optical configuration for embedded camera applications.
• 9G+IRCF construction combines a multi-element optical design with an integrated IR-cut filter configuration.

7.9mm M12 Low Distortion Lens Applications

Core Application Scenes

This 7.9mm M12 low distortion lens is designed for high-resolution imaging applications where the camera needs to capture a defined target area with substantially more detail than a short-focal-length wide-angle lens. Its 44° horizontal FOV provides a relatively focused viewing area, making it suitable for cameras positioned at a moderate distance from the subject.

The combination of 12.3MP resolution and < -2.4% distortion makes this lens particularly suitable for applications where image detail and geometric consistency are both important. It can be used in high-resolution embedded vision cameras, robotic observation modules, smart monitoring equipment, compact inspection systems, and AI-enabled imaging devices.

The specified compatibility with the Sony IMX477 1/2.3″ sensor is another important advantage for camera developers. Instead of treating the lens as a generic M12 optic, engineers can evaluate it as part of a defined lens-and-sensor combination, helping simplify optical selection during camera module development.

The 0.5m minimum object distance makes the lens more appropriate for medium-range imaging than the close-focus M12 models in this series. It can therefore be positioned farther from the target while maintaining a controlled field of view, which is useful for equipment monitoring, robotic observation, and defined-area surveillance.

For engineers developing high-resolution camera modules, Towin’s Sensor Guide provides guidance on matching lens specifications with sensor formats. The Lens Selection Guide can also help evaluate focal length, working distance, FOV, and resolution requirements.

Compatible Device List

• Sony IMX477 Camera Modules: Specifically evaluated for 1/2.3″ IMX477-based imaging systems requiring a compact M12 optical interface.
• High-Resolution Embedded Cameras: The 12.3MP optical specification supports detailed image acquisition in compact camera architectures.
• Robotic Vision Modules: The moderate FOV provides focused observation of work areas, objects, or operating environments without excessive scene expansion.
• Smart Monitoring Cameras: Controlled distortion and high resolution support detailed monitoring of defined areas.
• Compact Inspection Systems: The combination of high resolution and controlled distortion can support visual inspection and image-analysis workflows.
• AI Vision Devices: Detailed 12.3MP image input can provide richer visual data for computer vision and edge-AI processing.
• OEM/ODM Camera Modules: The M12×0.5 interface and defined optical configuration provide a practical platform for customized camera development.

For additional compact M12 optical options, explore Towin’s M12 Lenses. Engineers can use the FOV Calculator to estimate the image coverage provided by this 7.9mm focal length under different camera installation conditions.

For projects requiring a different focal length, sensor format, distortion target, or mechanical configuration, contact Towin for OEM/ODM optical development support.

Designed for high-resolution embedded vision, robotic observation, and controlled-field monitoring applications.

Frequently Asked Questions

Q: What type of lens is this 7.9mm M12 lens?
A: It is a fixed focal, low distortion M12 lens designed for 1/2.3″ image sensors and 12.3MP imaging. It features a 7.9mm focal length and < -2.4% distortion.

Q: Which sensor is this lens designed for?
A: The supplied specification identifies the Sony IMX477 as the reference sensor for the 1/2.3″ format. This provides a defined sensor platform for evaluating the lens-camera combination.

Q: What is the field of view of the 7.9mm lens?
A: On the specified 1/2.3″ IMX477 configuration, the lens provides a 54° diagonal FOV, 44° horizontal FOV, and 34° vertical FOV.

Q: Is this 7.9mm M12 lens a wide-angle lens?
A: No. Its 44° horizontal FOV and 34° vertical FOV provide a moderate, relatively focused viewing angle rather than the broad coverage associated with dedicated wide-angle lenses.

Q: What is the advantage of the 12.3MP resolution?
A: Its 12.3MP optical specification delivers rich image detail, benefiting visual inspection, detailed monitoring, robotics and computer‑vision applications that require fine feature retention.

Q: What does the < -2.4% distortion specification mean?
A: It indicates that the lens is designed to limit geometric deformation in the captured image. Controlled distortion can help maintain more consistent object shapes and spatial relationships across the image.

Q: What is the minimum object distance of this lens?
A: The specified minimum object distance is 0.5m. This makes the lens more suitable for applications where the camera is installed at a moderate distance from the target rather than directly adjacent to it.

Q: Does the IRCF specification mean that this is an IR corrected lens?
A: No. IRCF denotes an IR‑cut filter setup. By contrast, an IR‑corrected lens compensates focus shift between visible and NIR wavelengths, representing a distinct optical property.
