CCTV Lens – S06012805512MPF

S06012805512MPF is 6mm 3-Megapixel CCTV lens with Built-In Filter, 1/2.8″ Low F-number M12/S-mount lens, F1.2 High-resolution low light sensitive lens.

6mm Wide Angle CCTV Lens

This 6mm F1.2 M12 CCTV lens is a compact fixed focal lens designed for 1/2.8″ sensors and 3MP imaging applications. With a 65° diagonal field of view, F1.2 aperture, and integrated IRCF structure, it delivers bright and stable images for compact CCTV and low-light security camera systems.

Product Highlights at a Glance

• F1.2 large aperture for brighter imaging in low-light environments.
• 65° diagonal FOV provides broad scene coverage from a compact camera module.
• 3MP resolution supports standard high-definition security imaging.
• M12×0.5 mount enables easy integration into compact camera designs.
• 7G + IRCF optical structure supports consistent image performance across demanding lighting conditions.

Wide Angle CCTV Lens Applications

Core Application Scenes

This 6mm F1.2 M12 lens is designed for compact security imaging where moderate wide-angle coverage and strong light-gathering capability are both important. Its F1.2 aperture helps the camera capture usable images in dim indoor environments, entrance areas, corridors, retail spaces, and other locations where available illumination can change throughout the day.

The 65° diagonal field of view provides a practical balance between scene coverage and image detail. Unlike an extreme wide-angle or fisheye lens, this fixed focal configuration is suitable for applications that need broader coverage without requiring an excessively distorted perspective.

For embedded security equipment, the compact M12 lens interface makes integration easier in small camera housings and OEM camera modules. The 0.2m minimum object distance also allows the lens to image relatively nearby subjects, making it suitable for access points, indoor monitoring, equipment observation, and compact smart-security devices.

For systems that require additional optical guidance, the Lens Selection Guide can help engineers evaluate focal length, sensor format, field of view, and other lens-selection parameters before deployment.

Designed for compact CCTV surveillance and low-light security camera applications.

Compatible Device List

• 1/2.8″ CMOS Cameras: Optimized for compact cameras using 1/2.8″ image sensors and requiring up to 3MP imaging performance.
• CCTV Camera Modules: Suitable for fixed-focus security camera modules where a 65° diagonal FOV provides practical scene coverage.
• Indoor Security Cameras: F1.2 aperture supports brighter image capture in corridors, entrances, offices, retail areas, and other relatively low-light environments.
• Embedded Vision Devices: The M12×0.5 mount is suitable for compact embedded camera systems with limited installation space.
• OEM Security Equipment: The fixed-focus optical configuration can be integrated into customized camera housings and surveillance products.

For a broader selection of compact optics, explore M12 Lenses and the dedicated M12 Lens Solution.

Frequently Asked Questions

Q: What sensor size is this 6mm M12 lens designed for?
A: This lens is designed for 1/2.8″ image sensors and provides 3MP resolution performance for compatible camera systems.

Q: What is the field of view of this M12 lens?
A: The lens provides a 65° diagonal, 55° horizontal, and 30° vertical field of view.

Q: What is the advantage of the F1.2 aperture?
A: The F1.2 aperture provides strong light-gathering capability, helping maintain brighter images in low-light environments compared with lenses using smaller maximum apertures.

Q: Is this a fixed focal lens?
A: Yes. The 6mm focal length and fixed iris configuration make it a fixed focal M12 lens suitable for applications with a predefined viewing area.

Q: What type of camera uses an M12×0.5 lens mount?
A: M12×0.5 mounts are commonly used in compact CCTV cameras, embedded vision modules, security cameras, IoT imaging devices, and other small camera systems.

Q: What is the minimum object distance of this lens?
A: The minimum object distance is 0.2m, allowing the lens to capture relatively close subjects in compact surveillance and embedded imaging installations.

Q: Is this lens suitable for low-light CCTV applications?
A: Yes. Its F1.2 aperture is particularly useful for CCTV systems operating in dim indoor areas and other environments where available light is limited.

Q: Can Towin customize this M12 lens for an OEM camera project?
A: Towin can evaluate optical and mechanical requirements for OEM projects, including sensor compatibility, focal length, field of view, housing dimensions, and other application-specific requirements. Engineers can submit project requirements through the Contact Towin page.
