CCL2316MPR7
16mm CCTV lens, Ultra-low-distortion lens, F7.5 2/3″ M12-mount lens, 5-Megapixel, IR-corrected.
CCL2316MPR7 is 16mm High-resolution CCTV lens, Ultra-low-distortion lens, fixed F7.5 aperture 2/3″ M12-mount lens, 5-Megapixel, IR-corrected.
| IMAGE FORMAT | 2/3″ |
| FOCAL LENGTH | 16mm |
| F.O.V. | 38°(D) |
| 31°(H) | |
| 23.3°(V) | |
| RESOLUTION | 5MP |
| DISTORTION | <0.5% |
| APERTURE | F7.5 |
| MOUNT | M12X0.5 |
| IRIS | Fixed |
| T.T.L. | 21.1mm |
| M.O.D. | 0.3m |
| IR | Corrected |
