S04311808228F
Wide-angle low-distortion CCTV HD lens with Built-In Filter, 1/1.8″ M12/S-Mount 94° 8-Megapixel F2.8 security surveillance lens.
S04311808228F is Wide-angle low-distortion CCTV HD lens with Built-In Filter, 1/1.8″ M12/S-Mount 94° 8-Megapixel F2.8 security surveillance lens.
| IMAGE FORMAT | 1/1.8“ |
| FOCAL LENGTH | 4.3mm |
| F.O.V. | 94°(D) |
| 82°(H) | |
| 66°(V) | |
| RESOLUTION | 8 MP |
| DISTORTION | <-0.8% |
| APERTURE | F2.8 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.2m |
| T.T.L. | 25.4mm |
| CONSTRUCTION | 9G+IRCF |
