CCL12301720MPF
Fisheye lens HD CCTV IR corrected 1/2.3″ Φ4.8 195° M12 lens 8MP F2.0 360 panoramic security surveillance
CCL12301720MPF Fisheye lens HD CCTV IR corrected 1/2.3″ Φ4.8 195° M12 lens 8MP F2.0 360 panoramic security surveillance
| IMAGE FORMAT | Φ4.8mm, 1/2.3″ |
| FOCAL LENGTH | 1.7mm |
| F.O.V. | 195°(D) |
| 195°(H) | |
| 195°(V) | |
| RESOLUTION | 8 Megapixel |
| OPTICAL DISTORTION | <-95% |
| APERTURE | F2.0 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.1m |
| T.T.L. | 20.29mm |
| B.F.L. | 4.31mm |
| CONSTRUCTION | 6G+IRF |
Fisheye lens HD CCTV IR corrected Φ4.8 195° M12 lens 8MP F2.0 360 panoramic security surveillance
