C-Mount Lens – C0611018M20

C0611018M20 is 6mm High-Quality Wide-angle C-Mount lens, manual iris, 20-Megapixel Low distortion lens, High resolution Industrial Lens.

20MP 1.1″ C-Mount 6mm Wide Angle Low Distortion Machine Vision Lens

This 20MP 1.1″ C-Mount machine vision lens combines a 6mm focal length with an exceptionally wide 118° diagonal field of view and less than 2.5% TV distortion. Designed for high-resolution industrial imaging, it provides broad scene coverage while maintaining controlled geometric distortion for demanding vision applications.

The lens supports 1.1″ image sensors and up to 20MP resolution, making it suitable for high-detail imaging systems that require both a large image area and wide-angle coverage. Its F1.8–16 manual aperture provides flexible exposure control, while manual focus and a 0.1m minimum object distance support close-range imaging and system-level optical adjustment.

For applications requiring precise field coverage, users can also refer to the Lens Selection Guide and FOV Calculator to evaluate focal length and viewing requirements before integration.

Product Core Highlights

• 20MP high-resolution imaging for detailed industrial vision inspection.
• 1.1″ image format supports large-format high-resolution sensors.
• 118° diagonal FOV provides exceptionally broad scene coverage from a 6mm focal length.
• <2.5% TV distortion helps maintain geometric accuracy across a wide viewing area.
• F1.8–16 manual aperture provides flexible exposure control for different lighting conditions.

C-Mount Machine Vision Lens Applications

Core Application Scenes

This 20MP C-Mount wide angle lens is designed for industrial imaging systems where a conventional narrow-field lens cannot capture enough of the target area from a limited installation distance. Its 105° horizontal and 86° vertical FOV allow a single camera to cover a broad inspection zone while retaining 20MP image detail.

In factory automation environments, the lens can be used for large-area visual inspection, assembly-line monitoring, component positioning and robotic workspace observation. The <2.5% TV distortion specification is particularly useful when image geometry needs to remain controlled across a wide field of view.

The 0.1m minimum object distance also makes the lens suitable for compact inspection stations where the camera must be installed relatively close to the inspected object. Manual focus and manual iris adjustment allow optical parameters to be tuned during machine setup according to working distance and illumination.

For applications involving robotic inspection and large working areas, this lens can be integrated into Robotics Vision solutions where wide scene coverage and high-resolution image data are required.

Compatible Device List

• Industrial Cameras: Compatible with C-Mount industrial cameras using 1.1″ image sensors and supporting resolutions up to 20MP.
• Machine Vision Systems: Suitable for high-resolution inspection cameras used in automated optical inspection, dimensional observation and production-line monitoring.
• Factory Automation Equipment: The wide FOV helps cover larger work areas when camera mounting space or installation distance is limited.
• Robotic Vision Systems: The broad viewing angle can help capture workspaces, components and operating areas for robotic perception.
• Large-Sensor Vision Platforms: Designed for applications requiring coverage of a 1.1″ sensor without sacrificing high-resolution imaging capability.
• Manual Optical Integration: Manual iris, focus and zoom functions allow optical adjustment during machine setup and system calibration.

Designed for wide-field high-resolution machine vision and industrial inspection applications.

For selecting the appropriate sensor and lens combination, the Sensor Guide provides useful background on sensor format and optical compatibility. Users can also explore C-Mount Lenses for other high-resolution industrial lens configurations.

Frequently Asked Questions

Q: What sensor size is this 6mm lens designed for?
A: This lens is designed for a 1.1″ image format, making it suitable for industrial cameras equipped with 1.1″ sensors.

Q: What is the field of view of this 20MP C-Mount lens?
A: The lens provides a 118° diagonal FOV, 105° horizontal FOV and 86° vertical FOV, giving it very broad scene coverage.

Q: Is this lens suitable for machine vision applications?
A: Yes. Its 20MP resolution, 1.1″ image format, wide FOV and controlled <2.5% TV distortion make it suitable for high-resolution machine vision and industrial inspection systems.

Q: Does the lens have low distortion?
A: Yes. The specified TV distortion is less than 2.5%, which helps reduce geometric deformation in wide-angle imaging applications.

Q: What is the minimum object distance of this lens?
A: The M.O.D. is 0.1m, allowing the lens to be used for relatively close-range industrial imaging and inspection setups.

Q: Can the aperture be adjusted manually?
A: Yes. The lens features a manual F1.8–16 aperture, allowing users to adjust light transmission according to the imaging environment.

Q: Does this lens support manual focus and zoom?
A: Yes. Both focus and zoom are specified as manual, providing optical adjustment flexibility during camera installation and system configuration.

Q: How can I determine whether this 6mm lens provides the required coverage?
A: You can use Towin’s FOV Calculator to evaluate field of view based on sensor and focal-length requirements. For broader lens selection considerations, see the Lens Basics section.
