Wide Angle Lens – S0401171211669

S0401171211669 is Wide-angle 8-Megapixel M12 lens, F1.6 Aperture, IP67/IP69K waterproof rating, suitable for surveillance or automotive applications.

4.0mm M12 8MP Wide Angle Lens

This 4.0mm M12 wide angle lens is designed for 1/1.73-inch 8MP sensors such as the OX08B40, providing an extensive 140° diagonal and 121° horizontal field of view. With an F1.6 aperture, 4G3MG optical structure, and IP67/IP69K protection, it is suitable for automotive, outdoor, smart traffic, and high-resolution wide-area vision systems.

M12 Wide Angle Lens Core Highlights

• 140° ultra-wide FOV: Provides extensive scene coverage with 121° horizontal field of view.
• 8MP OX08B40 compatibility: Designed for high-resolution imaging using a 1/1.73-inch sensor.
• F1.6 large aperture: Provides strong light-gathering capability for changing or challenging lighting conditions.
• 4G3MG optical structure: Compact optical configuration designed for wide-angle imaging.
• IP67 / IP69K protection: Suitable for automotive, outdoor, and harsh-environment vision applications.

4.0mm M12 Wide Angle Lens Applications

Core Application Scenes

The combination of 4.0mm focal length, 140° diagonal FOV, 8MP resolution, and F1.6 aperture makes this lens suitable for applications requiring broad scene coverage together with high image detail.

Typical applications include:

• Automotive surround vision: The 140° diagonal FOV provides extensive coverage around vehicles and equipment.
• Vehicle-mounted monitoring: The 121° horizontal FOV is suitable for capturing broad lateral scenes.
• Smart traffic imaging: The combination of 8MP resolution and wide-angle coverage supports detailed road-scene monitoring.
• Outdoor intelligent cameras: IP67/IP69K protection supports demanding outdoor installations.
• Embedded AI vision: High-resolution wide-area imaging provides extensive visual information for object detection and scene analysis.
• Robotics vision: The broad FOV can support environmental perception and obstacle awareness.
• Wide-area industrial monitoring: The optical configuration can cover large areas from a relatively compact camera position.

Designed for automotive surround vision, smart traffic, outdoor monitoring, robotics vision, and high-resolution wide-area imaging applications.

For compact optical integration, see TOWIN’s M12 Lens Solutions. For similar wide-angle and wide angle optical configurations, explore the Wide Angle Lenses categories.

Compatible Device List

• 1/1.73-inch OX08B40 camera modules — matched to the specified 8MP sensor.
• Automotive surround-view cameras — IP67/IP69K protection supports demanding vehicle environments.
• Smart traffic cameras — 8MP resolution provides detailed road and traffic imagery.
• Outdoor AI cameras — wide FOV provides broad visual input for intelligent analysis.
• Robotics vision modules — broad scene coverage supports environmental perception.
• Industrial outdoor cameras — IP69K protection is suitable for demanding installation environments.
• Embedded M12 camera systems — M12x0.5 mounting supports compact optical integration.

Ultra-Wide Optical Performance

The lens provides an impressive 140° diagonal field of view with the 1/1.73-inch OX08B40 sensor. The corresponding horizontal and vertical FOVs are approximately 121° and 67°.

The specified < -57% distortion is characteristic of the lens’s extreme wide-angle optical behavior. This is not a low-distortion design; instead, the optical configuration prioritizes capturing a very large scene within a compact camera system.

This makes the lens suitable for applications where wide-area coverage and situational awareness are more important than maintaining rectilinear image geometry.

For applications requiring accurate geometric imaging, TOWIN’s Low Distortion Lens category provides alternative optical solutions.

8MP OX08B40 Compatibility

The lens is specifically designed for the 1/1.73-inch OX08B40 8MP sensor, allowing the optical system to combine high image resolution with a very broad field of view.

The resulting configuration provides:

• 8MP resolution
• 140° diagonal FOV
• 121° horizontal FOV
• 67° vertical FOV
• 4.0mm focal length
• F1.6 aperture

This combination is particularly useful for vision systems that need to observe a broad scene while retaining sufficient image detail for intelligent analysis.

For additional information about sensor format and lens compatibility, see TOWIN’s Sensor Guide.

F1.6 Large Aperture

The F1.6 aperture provides a relatively high level of light-gathering capability, which can be beneficial in automotive, outdoor, and other variable-light environments.

The combination of F1.6 aperture and an 8MP sensor can support applications where maintaining usable image brightness and image detail is important.

Actual low-light performance will also depend on sensor sensitivity, exposure settings, illumination, and the complete camera system.

Frequently Asked Questions

Q1: What sensor is this 4.0mm M12 lens designed for?
A: It is designed for the 1/1.73-inch OX08B40 sensor with 8MP resolution.

Q2: What is the field of view of the 4.0mm lens?
A: With the OX08B40 sensor, the lens provides approximately 140° diagonal, 121° horizontal, and 67° vertical FOV.

Q3: Is this lens a wide-angle lens?
A: Yes. Its 140° diagonal FOV places it firmly in the wide-angle category.

Q4: Is this lens also considered a wide angle lens?
A: Yes. The combination of 140° FOV and < -57% distortion indicates an extreme wide-angle optical configuration that can be categorized as wide angle.

Q5: Is this a low distortion lens?
A: No. The specified distortion is below -57%, so the lens is designed primarily for extensive scene coverage rather than low geometric distortion.

Q6: What is the advantage of the F1.6 aperture?
A: F1.6 provides strong light-gathering capability, which can help maintain image brightness in changing or relatively low-light conditions.

Q7: Is this lens suitable for automotive applications?
A: Yes. The IP67/IP69K protection makes it suitable for automotive and harsh outdoor vision applications.

Q8: What does the 4G3MG optical structure mean?
A: It indicates the lens uses a 4G3MG optical construction. The optical design is optimized for the specified wide-angle 8MP imaging configuration.
