S03012811517F
3.0mm High Resolution wide-angle lens, 8 Megapixel S-Mount Lens (F1.7), 1/2.8″ Low Light Sensitive Lens.
S03012811517F is 3.0mm High Resolution wide-angle lens with Built-In Filter, 8 Megapixel Low F-number S-Mount Lens (F1.7), 1/2.8″ Low Light Sensitive Lens.
| IMAGE FORMAT | 1/2.8″ |
| FOCAL LENGTH | 3.0mm |
| F.O.V. | 140°(D=6.43) |
| 115°(H=5.60) | |
| 60°(V=3.18) | |
| RESOLUTION | 8 MegaPixel |
| TV DISTORTION | <-18% |
| APERTURE | F1.7 |
| MOUNT | M12X0.5 |
| IRIS | Fixed |
| FOCUS | Manual |
| ZOOM | Fixed |
| T.T.L. | 22mm |
| STRUCTURE | 7G+IRCF |
