S02013014024F67
Wide-angle M12/S-Mount Megapixel CCTV lens with Built-In IR Filter, 178°(D) F.O.V. for 1/3″ sensor, F2.4 aperture, IP67 Waterproof Automotive Lens.
S02013014024F67 is Wide-angle M12/S-Mount Megapixel CCTV lens with Built-In IR Filter, 178°(D) F.O.V. for 1/3″ sensor, F2.4 aperture, IP67 Waterproof Automotive Lens.
| IMAGE FORMAT | Max Φ6.4mm |
| FOCAL LENGTH | 2.0mm |
| F.O.V. 1/3″ | 178°(D) |
| 140°(H) | |
| 102°(V) | |
| DISTORTION | <-95% |
| F.O.V. 1/4″ | 130°(D) |
| 102°(H) | |
| 76°(V) | |
| DISTORTION | <-39% |
| RESOLUTION | Megapixel |
| APERTURE | F2.4 |
| MOUNT | M12X0.5 |
| IRIS | Fixed |
| B.F.L. | 4.5mm |
| M.O.D. | 0.1m |
| STRUCTURE | 6G+IRCF |
| WATERPROOF | IP67 |
