Low Distortion Lens – S11013202340

S11013202340 is 13-Megapixel Low distortion lens for machine vision, 1/3.2″ M12/S-Mount lens with 29.5° diagonal FOV, F4.0 aperture, and 0.3m MOD.

11mm 13MP M12 Low Distortion Fixed Focal Lens

This 11mm M12 fixed focal lens is designed for 1/3.2″ image sensors and high-resolution 13MP imaging applications. With support for the AR1335 sensor format, a 29.5° diagonal field of view, and a compact M12x0.35 mount, it provides detailed imaging for space-constrained camera modules.

The F4.0 fixed iris and 0.3m minimum object distance make this lens suitable for controlled imaging environments where high resolution and a relatively narrow field of view are more important than broad scene coverage.

Product Core Highlights

• 13MP resolution supports high-detail imaging with compact 1/3.2″ sensors.
• AR1335 compatibility makes it suitable for specific high-resolution camera architectures.
• 11mm focal length provides relatively narrow, controlled image coverage.
• M12x0.35 mount supports compact embedded camera integration.
• 0.3m M.O.D. enables close-range imaging without requiring an extremely short focal length.

11mm M12 Low Distortion Lens Applications

Core Application Scenes

This 11mm lens is optimized for applications that combine a small image sensor with high-resolution imaging requirements. Its 13MP optical specification and AR1335 compatibility make it particularly relevant to compact camera modules where available installation space is limited but detailed image capture is still required.

The relatively narrow 29.5° diagonal field of view is useful when the camera needs to concentrate on a defined target rather than capture a large surrounding area. This can benefit localized inspection, compact object recognition, detailed monitoring, and embedded AI vision systems.

For machine vision applications, the 11mm focal length can be used when the target is positioned at approximately 0.3m or farther and the system requires a controlled viewing region. The F4.0 fixed iris is also appropriate for systems operating under managed and repeatable lighting conditions.

Because this lens is designed around the 1/3.2″ format, engineers should confirm sensor compatibility before selecting it for a camera platform. The Sensor Guide can help determine whether the image format is appropriate for the intended camera sensor.

Compatible Device List

• AR1335 Camera Modules: High-resolution compact camera designs using the specified sensor format.
• Embedded AI Cameras: Small imaging modules for object recognition and image analysis.
• Machine Vision Cameras: Compact inspection systems requiring detailed image capture.
• Smart Monitoring Devices: Fixed-view cameras focused on defined target areas.
• Robotics Vision Modules: Compact cameras for localized object detection and inspection.
• OEM Imaging Systems: Customized camera products requiring 13MP performance and M12x0.35 mounting.

Designed for high-resolution embedded vision application where compact size, controlled field of view, and detailed imaging are required.

When determining whether the 11mm focal length provides sufficient target coverage, the FOV Calculator can be used to estimate the image area based on the sensor and working distance.

Frequently Asked Questions

Q: What sensor size is this 11mm M12 lens designed for?
A: It is designed for a 1/3.2″ image format and is specified for use with the AR1335 sensor.

Q: What resolution does this lens support?
A: The lens is specified for 13MP resolution, making it suitable for high-detail imaging applications.

Q: What is the field of view of the 11mm lens?
A: The specified field of view is 29.5° diagonal, 23.3° horizontal, and 26.9° vertical according to the provided AR1335 specification.

Q: Is this lens suitable for machine vision?
A: Yes. The 13MP resolution, controlled field of view, fixed focal length, and compact M12 mount make it suitable for selected machine vision and embedded inspection systems.

Q: Is this an ultra-low distortion lens?
A: No. The specified distortion is <2.8%, so it is better positioned as a high-resolution fixed focal lens rather than an ultra-low-distortion optical solution.

Q: What is the minimum object distance?
A: The minimum object distance is 0.3m.

Q: What type of mount does this lens use?
A: It uses an M12x0.35 threaded mount. The mating camera housing or holder should use the same thread specification.

Q: Is this lens suitable for wide-angle imaging?
A: No. Its 29.5° diagonal field of view is relatively narrow, making it more appropriate for focused imaging of defined target areas than broad scene capture.
