S08011804728
Low distortion lens for machine vision, 1/1.8″ M12/S-mount 8mm wide-angle lens, F2.8, 8-Megapixel.
S08011804728 is Low distortion lens for machine vision, 1/1.8″ M12/S-mount 8mm wide-angle lens, fixed F2.8 aperture, high resolution 8-Megapixel.
| IMAGE FORMAT | Max Φ11mm |
| FOCAL LENGTH | 8mm |
| F.O.V.(1/1.8″) | 57°(D) |
| 47°(H) | |
| 36°(V) | |
| RESOLUTION | 8MP |
| TV DISTORTION | <0.3% |
| APERTURE | F2.8 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.12m |
| B.F.L. | 9.36mm |
| T.T.L. | 25mm |
| STRUCTURE | Without IRCF |
