IR Corrected Lens – CCL23080MP

CCL23080MP 8mm 2/3″ M12 IR corrected lens with F1.8 aperture, 70° FOV and megapixel resolution for compact machine vision and imaging.

8mm 2/3″ Megapixel M12 IR Corrected Fixed Focal Lens

This 8mm M12 fixed focal lens is designed for compact imaging systems using 2/3″ image sensors and requiring stable megapixel imaging across visible and near-infrared wavelengths. With a 70° diagonal field of view, F1.8 fixed aperture, and IR corrected optical design, this M12 lens provides a versatile solution for embedded cameras, compact machine vision systems, smart monitoring equipment, and other imaging applications where consistent optical performance across different wavelengths is important.

Product Core Highlights

• 2/3″ megapixel imaging: Designed to cover larger 2/3″ sensors while maintaining megapixel-level imaging performance.
• 8mm fixed focal length: Provides a balanced 70° diagonal FOV for compact imaging systems requiring controlled scene coverage.
• F1.8 aperture: Provides a relatively bright optical configuration for imaging applications operating under varying illumination conditions.
• IR corrected optical design: Helps maintain consistent focus and image performance across visible and near-infrared wavelengths.
• Compact M12 configuration: The M12 × 0.5 mount and Φ14 × 11.8mm dimensions support integration into compact camera assemblies.

M12 IR Corrected Lens Applications

This 8mm M12 IR corrected lens is well suited to imaging systems that need more than a basic visible-light camera lens. Its IR corrected optical design makes it particularly useful in applications where the camera may operate with near-infrared illumination or switch between visible and IR imaging conditions.

Typical applications include compact machine vision cameras, embedded inspection systems, smart security cameras, intelligent monitoring devices, biometric imaging equipment, robotics vision modules, and near-infrared imaging systems. The 8mm focal length and 70° diagonal FOV provide a practical balance between scene coverage and image perspective for medium-distance imaging.

The lens can be integrated with 2/3″ megapixel CMOS sensors and camera modules using an M12 × 0.5 interface. Its F1.8 aperture is also beneficial for compact imaging devices where available light can vary during operation.

For applications involving sensor format compatibility, refer to the Sensor Guide. For selecting the appropriate focal length, sensor and field of view, the Lens Selection Guide provides additional guidance.

As part of the M12 Lenses portfolio, this model is suitable for compact camera designs where an M12 interface, larger sensor coverage and IR corrected performance are required.

Frequently Asked Questions

Q: What type of lens is this?
A: This is an 8mm fixed focal M12 lens designed for 2/3″ megapixel imaging systems, featuring an F1.8 aperture and IR corrected optical design.

Q: What sensor size is supported by this M12 lens?
A: The lens is designed for 2/3″ image sensors and provides megapixel-level imaging performance for compatible camera systems.

Q: What is the field of view of the 8mm lens?
A: The lens provides a 70° diagonal, 59° horizontal, and 46° vertical field of view on the specified sensor format.

Q: What does IR corrected mean for this lens?
A: IR correction is designed to reduce focus shifts between visible and near-infrared wavelengths, helping maintain more consistent image focus when the imaging system operates with IR illumination.

Q: Is this an M12 low distortion lens?
A: The specified distortion is below -0.9%. While the distortion is controlled for many imaging applications, this model should not be positioned as a dedicated low-distortion lens compared with products specified below 0.5%.

Q: What is the advantage of the F1.8 aperture?
A: The F1.8 aperture provides a relatively bright optical path, which can help the camera collect more light in indoor, low-light, or near-infrared imaging environments.

Q: What mount does this lens use?
A: It uses an M12 × 0.5 threaded mount, making it compatible with camera modules and imaging devices designed for the standard M12 lens interface.

Q: Can TOWIN customize this M12 IR corrected lens?
A: TOWIN can evaluate customized optical and mechanical requirements based on sensor format, focal length, FOV, resolution, wavelength range, mounting interface and installation dimensions. Contact TOWIN Lens for project-specific requirements.
