Automotive Lens – S06012006428F67

S06012006428F67   1/2.3″ wide angle 12MP Waterproof IP67 Automotive lens , well match IMX477, HFOV 62 degree, TV distortion less than 3%

6mm M12 12MP IP67 Waterproof Automotive Lens

This 6mm M12 automotive lens is a high-resolution waterproof lens designed for vehicle-mounted cameras, automotive vision systems, and outdoor imaging applications. With 12MP resolution, an 81° diagonal FOV on a 1/2″ sensor, TV distortion below 2.9%, and an IP67 waterproof structure, it provides a strong balance of image detail, wide coverage, and environmental protection.

Featuring an M12×0.5 mount, F2.8 aperture, 0.2m minimum object distance, 5.0mm BFL, and 6G+IRCF optical construction, this compact automotive lens is suitable for demanding vehicle imaging systems that require reliable performance in outdoor and variable-weather conditions.

IP67 Waterproof Automotive Lens Core Highlights

• 12MP High-Resolution Imaging: Provides detailed image capture for advanced automotive cameras and vehicle vision systems.
• IP67 Waterproof Protection: The sealed optical structure is designed to withstand dust and water exposure in demanding outdoor vehicle environments.
• Low-Distortion Wide-Angle Design: With 81° diagonal FOV and TV distortion below 2.9%, the lens provides broad coverage while maintaining controlled image geometry.
• IR Cut Filter Integration: The 6G+IRCF optical construction supports day-and-night imaging requirements for automotive and outdoor camera systems.
• Compact M12×0.5 Mount: Provides a practical mechanical interface for compact vehicle-mounted cameras and embedded imaging modules.

IP67 Waterproof Automotive Lens Applications

Core Application Scenes

This 6mm M12 automotive lens is designed for vehicle imaging systems that require reliable optical performance in outdoor environments. Its 12MP resolution captures fine image details, while the 81° diagonal FOV on a 1/2″ sensor provides a useful viewing range for monitoring the area surrounding a vehicle.

The IP67 waterproof design adds protection against dust and water, making the lens suitable for exterior camera installations exposed to rain, road spray, dust, and changing environmental conditions.

Designed for waterproof automotive camera and vehicle vision applications.

Typical applications include:

• Automotive surround-view cameras
• Vehicle monitoring cameras
• ADAS camera systems
• Front-view automotive cameras
• Rear-view and side-view cameras
• Parking assistance systems
• Blind-spot monitoring cameras
• Commercial vehicle cameras
• Outdoor vehicle inspection cameras
• Intelligent transportation imaging
• Fleet monitoring systems
• Vehicle-mounted vision systems

For advanced driver assistance and vehicle perception projects, this lens can be integrated into TOWIN’s ADAS Solutions.

For broader traffic monitoring and intelligent transportation applications, see TOWIN’s Smart Traffic Solutions.

Compatible Device List

The M12×0.5 mounting interface and compact 20.5mm TTL make this lens suitable for a variety of embedded automotive and outdoor imaging devices, including:

• 1/2″ automotive camera modules
• 1/2.3″ camera modules
• 12MP vehicle cameras
• ADAS camera modules
• Surround-view camera systems
• Parking cameras
• Side-view automotive cameras
• Rear-view camera modules
• Commercial vehicle cameras
• Outdoor monitoring cameras
• Vehicle-mounted inspection cameras
• OEM automotive imaging systems

The listed FOV is 81° diagonal, 64° horizontal, and 47° vertical on a 1/2″ sensor. When paired with a 1/2.3″ sensor, the FOV changes to 78° diagonal, 62° horizontal, and 45° vertical.

For more information about matching sensor formats and lens image coverage, refer to TOWIN’s Sensor Guide.

Optical Design Considerations

The 6mm focal length provides a moderate wide-angle perspective that is well suited to vehicle-mounted imaging where both coverage and image detail are required. Compared with extremely short focal length fisheye optics, this design provides a more controlled perspective and significantly lower distortion.

With TV distortion below 2.9%, the lens helps maintain recognizable object shapes and road-scene geometry, which can be beneficial for automotive image analysis and monitoring.

The 6G+IRCF construction incorporates an infrared cut filter for conventional visible-light imaging and helps control unwanted infrared wavelengths reaching the image sensor. For day-and-night automotive systems requiring active IR imaging, the exact optical configuration should be evaluated according to the camera architecture.

The IP67 protection is particularly important when the camera is installed outside the vehicle. It helps protect the optical assembly from dust ingress and water exposure, supporting more reliable operation in outdoor environments.

For additional information about distortion and lens selection, see the Distortion Guide and Lens Selection Guide.

Frequently Asked Questions

Q: What type of automotive lens is this?
A: It is a 6mm M12 12MP waterproof automotive lens with an IP67 protection rating, 81° diagonal FOV on a 1/2″ sensor, and TV distortion below 2.9%.

Q: Is this lens suitable for ADAS cameras?
A: Yes. Its 12MP resolution, controlled distortion, moderate wide-angle FOV, compact M12×0.5 mount, and IP67 protection make it suitable for various automotive vision and ADAS camera designs, subject to the system’s specific optical requirements.

Q: What does IP67 mean for this automotive lens?
A: IP67 indicates that the optical assembly is designed for protection against dust ingress and temporary water immersion under defined test conditions. This makes it suitable for many outdoor and vehicle-mounted applications.

Q: What is the FOV of the 6mm lens?
A: On a 1/2″ sensor, the lens provides 81° diagonal, 64° horizontal, and 47° vertical FOV. On a 1/2.3″ sensor, the FOV is 78° diagonal, 62° horizontal, and 45° vertical.

Q: Why is low distortion important for automotive cameras?
A: Controlled distortion helps maintain more natural object shapes and scene geometry, which can improve the consistency of images used for vehicle monitoring, parking assistance, object detection, and other automotive vision tasks.

Q: What cameras are compatible with this M12 lens?
A: The M12×0.5 mount can be used with compatible 1/2″ and 1/2.3″ camera modules, including automotive cameras, ADAS cameras, parking cameras, surround-view systems, and other vehicle-mounted imaging devices.

Q: Can TOWIN customize this IP67 automotive lens?
A: Yes. TOWIN supports OEM and ODM optical development and can customize specifications such as focal length, FOV, distortion, sensor format, mechanical dimensions, mounting interface, and environmental protection according to project requirements. Contact the TOWIN engineering team for your project requirements.
