S02112810822F
2.1mm 8-megapixel wide-angle CCTV lens, 1/2.8″ M12/S-mount , low distortion lens, suitable for surveillance applications.
S02112810822F is 2.1mm 8-megapixel wide-angle CCTV lens, 1/2.8″ M12/S-mount , low distortion lens, suitable for surveillance applications.
| IMAGE FORMAT | 1/2.8″ |
| FOCAL LENGTH | 2.1mm |
| F.O.V.(IMX415) | 120°(D=6.43) |
| 110°(H=5.60) | |
| 74°(V=3.18) | |
| RESOLUTION | 8 MP |
| TV DISTORTION | <-4% |
| APERTURE | F2.2 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.1m |
| T.T.L. | 24.50mm |
| CONSTRUCTION | 4G2P+IRCF |
