CCL13040MP
Low distortion wide angle 4mm M12 mount lens 1/3″ with HD 3 Megapixel for rectilinear scanning
CCL13040MP Low distortion wide angle 4mm M12 mount lens 1/3″ with HD 3 Megapixel for rectilinear scanning
| IMAGE FORMAT | 1/3″ |
| FOCAL LENGTH | 4.0mm |
| F.O.V. | 76°(D) |
| 64°(H) | |
| 49°(V) | |
| RESOLUTION | 5 MP |
| DISTORTION | <-0.2% |
| APERTURE | F2.8 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.1m |
| T.T.L. | 22mm |
| DIMENSION | Φ14×18.7mm |
| CONSTRUCTION | 2G2P |
CCL13040MP Low distortion wide angle 4mm M12 mount lens with HD 3 Megapixel for rectilinear scanning
Online contact
| SENSOR | |
|---|---|
| E.F.L. | |
| H. F.O.V. | |
| FNo. | |
| Max Dist. | |
| IRIS | |
| MOUNT | |
| RESOLUTION | |
| T.T.L.(mm) | |
| FEATURE | |
| MARK |
