Wide angle M12 S-mount board lens 2.5mm short TTL OV4689 automotive car rear view
CCL129025624MPR Wide angle M12 S-mount board lens 2.5mm short TTL OV4689 automotive car rear view
| IMAGE FORMAT | 1/2.9″ |
| FOCAL LENGTH | 2.56mm |
| F.O.V.(sensor OV4689) | 154°(D) |
| 130°(H) | |
| 71°(V) | |
| RESOLUTION | 4 Megapixel |
| OPTICAL DISTORTION | <-72% |
| TV DISTORTION | <-9%(H) |
| APERTURE | F2.4 |
| MOUNT | M12X0.5 |
| IRIS | Fixed |
| T.T.L. | 14.5mm |
| B.F.L. | 4.38mm |
| M.B.F.L. | 3.8mm |
| M.O.D. | 0.2m |
| LENS COMPOMEMT | 6G |
CCL129025624MPR Wide angle M12 S-mount board lens 2.5mm short TTL OV4689 automotive car rear view
