CCL1212MPF
Low distortion M12 S-mount board lens 1/1.8″ 12mm HD rectilinear 5MP for scanning short TTL
CCL1212MPF Low distortion M12 S-mount board lens 1/1.8″ 12mm HD rectilinear 5MP for scanning short TTL
| IMAGE FORMAT | 1/2″, 1/1.8″, 2/3″ |
| FOCAL LENGTH | 12mm |
| F.O.V.(1/2″) | 37°(D) |
| 30°(H) | |
| 23°(V) | |
| RESOLUTION | 5 MP |
| DISTORTION | <-1.5% |
| APERTURE | F2.8 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| R.I. | >82.5% |
| T.T.L. | 18.05mm |
| CONSTRUCTION | 6G+IRF |
CCL1212MPF Low distortion M12 S-mount board lens 12mm HD rectilinear 5MP for scanning short TTL
