S03712310120
3.7mm Wide-angle HD lens 1/2.3″ F2.0 M12/S-mount lens, 5 Megapixel IP67 waterproof automotive lens.
S03712310120 is 3.7mm Wide-angle HD lens 1/2.3″ F2.0 High-Resolution M12/S-mount lens, 5 Megapixel IP67 Durable waterproof automotive lens.
| IMAGE FORMAT | 1/2.3″ |
| FOCAL LENGTH | 3.7mm |
| F.O.V.@1/2.3″ | 132°(D) |
| 101°(H) | |
| 74°(V) | |
| F.O.V.@1/2.7″ | 120°(D) |
| 97°(H) | |
| 52°(V) | |
| DISTORTION | <-31% |
| RESOLUTION | 5 MP |
| APERTURE | F2.0 |
| MOUNT | M12X0.5 |
| B.F.L. | 5.39mm |
| M.O.D. | 0.2m |
| CONSTRUCTION | 6G |
| WATERPROOF | IP67 |
