Wide Angle Lens – S03412710720

S03412710720 is 1/2.7″ 3.4mm High-Performance wide angle lens, F2.0 S-Mount Lenses with Low F-number (Fast Lenses), 2 Megapixel resolution lens.

3.4mm M12 Wide Angle Lens

The 3.4mm 2MP M12 wide angle lens is designed for 1/2.7″ OV2710 image sensors, providing a wide 136° diagonal field of view for compact vision systems that need broad scene coverage from a short working distance. With a fixed F2.0 aperture, 0.2m minimum object distance, and M12×0.5 mount, this lens provides a practical optical solution for embedded cameras, industrial monitoring, smart security, robotics, and other space-constrained imaging applications.

Its 3.4mm focal length combines a wide viewing angle with a compact 20mm TTL structure, making it suitable for applications where camera size and installation space are important. The 5.10mm BFL also supports integration into compact camera modules built around the 1/2.7″ OV2710 sensor.

For additional M12 optical options, explore TOWIN’s M12 Lenses and compare other wide-angle configurations for different sensor sizes and imaging requirements.

M12 Wide Angle Lens Core Highlights

• 136° Wide-Angle Coverage – The 3.4mm focal length provides a 136° diagonal FOV, helping compact cameras capture a broad scene.
• 2MP OV2710 Compatibility – Designed for 1/2.7″ OV2710 sensors and suitable for embedded camera architectures.
• Compact M12×0.5 Mount – The standard M12 interface simplifies integration into compact industrial and smart-camera systems.
• F2.0 Fixed Aperture – Provides a practical balance between light transmission and optical system simplicity.
• Short-Distance Imaging – A 0.2m MOD supports applications requiring wide-area imaging from relatively close installation distances.

M12 Wide Angle Lens Applications

Core Application Scenes

The combination of a 3.4mm focal length, 136° diagonal FOV, 0.2m MOD, and compact M12×0.5 mount makes this lens particularly suitable for systems that need broad coverage without using a physically large optical assembly.

Typical applications include:

• Embedded industrial cameras
• Machine vision monitoring
• Smart security cameras
• Indoor area monitoring
• Robotics vision systems
• Compact inspection cameras
• Access and entrance monitoring
• Wide-area equipment monitoring
• Compact IoT imaging devices

Designed for compact wide-area vision applications, this lens can help reduce the number of cameras required when a single camera needs to cover a relatively large scene.

For industrial inspection and automated imaging projects, see TOWIN’s Machine Vision solutions. For security-oriented camera systems, the Smart Security solution provides additional application references.

Compatible Devices

This 3.4mm M12 lens can be integrated into:

• 1/2.7″ OV2710 camera modules
• Compact M12 camera assemblies
• Embedded vision cameras
• Industrial monitoring cameras
• Robotics camera modules
• Smart security camera modules
• Space-constrained imaging devices

When selecting a lens for a specific sensor, the relationship between sensor format, focal length, and field of view should be evaluated together. TOWIN’s Sensor Guide provides additional information for sensor and lens matching.

Optical Design Considerations

The 136° diagonal FOV makes this 3.4mm lens suitable for applications where scene coverage is more important than minimizing wide-angle geometric distortion. With TV distortion below -17%, system designers should consider the imaging requirements of the application when evaluating object-position accuracy.

For applications where geometric accuracy is critical, review TOWIN’s Distortion Guide before selecting the final optical configuration.

The 0.2m MOD is also useful for compact camera installations where the lens must capture nearby objects while maintaining a broad viewing area. For more detailed focal-length and FOV evaluation, the FOV Calculator can help estimate scene coverage.

Frequently Asked Questions

Q: What sensor is this 3.4mm M12 lens designed for?
A: This lens is designed for a 1/2.7″ image format and is specified for the OV2710 sensor, with a resolution of 2 megapixels.

Q: What is the field of view of the 3.4mm lens?
A: With the 1/2.7″ OV2710 sensor, the lens provides a 136° diagonal, 107° horizontal, and 55° vertical field of view.

Q: Is this a wide-angle M12 lens?
A: Yes. Its 3.4mm focal length and 136° diagonal FOV make it a wide-angle M12 lens for applications requiring broad scene coverage.

Q: What is the minimum object distance of this lens?
A: The specified minimum object distance is 0.2m, making the lens suitable for relatively close-range wide-area imaging.

Q: What mount does this lens use?
A: The lens uses an M12×0.5 mount, which is widely used for compact embedded cameras and small vision modules.

Q: Is the aperture adjustable?
A: No. This model uses a fixed F2.0 aperture and fixed iris configuration.

Q: Is this lens suitable for machine vision applications?
A: It can be used in machine vision monitoring and compact inspection systems where wide scene coverage is required. For precision inspection, the application’s required distortion, resolution, working distance, and sensor matching should be evaluated together.

Q: Where can I find other M12 lens options?
A: You can explore TOWIN’s M12 lens range for additional focal lengths and optical configurations.
