2.4mm High-Resolution Wide Angle Lens, 5-Megapixel M12/S-Mount HD lens, Security Surveillance Lens.
S02412514828F – 2.4mm High-Resolution Wide Angle Lens with Built-In Filter, 5-Megapixel M12/S-Mount HD lens, fixed F2.8 aperture Security Surveillance Lens.
| IMAGE FORMAT | Max Φ7.5mm |
| FOCAL LENGTH | 2.4mm |
| F.O.V.(AR1335) | 150°(D=5.76) |
| 120°(H=4.63) | |
| 86°(V=3.43) | |
| DISTORTION | <-39% (H) |
| RESOLUTION | 5 MP |
| APERTURE | F2.8 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.2m |
| B.F.L. | 3.99mm |
| T.T.L. | 29.29mm |
| STRUCTURE | 7G+IRCF |
