CCL117032MP-12MP ultra-wide-angle lens 3.2mm 160° F2.0 manual focus IR correction
CCL117032MP-12MP ultra-wide-angle lens 3.2mm 160° F2.0 manual focus IR correction
| IMAGE FORMAT | 1/1.7″ |
| FOCAL LENGTH | 3.2mm |
| F.O.V. | 160°(D) |
| 131°(H) | |
| 100° (V) | |
| RESOLUTION | 12 MP |
| APERTURE | F2.0 |
| DISTORTION | <-63% |
| MOUNT | M12X0.5 |
| IRIS | Fixed |
| FOCUS | Manual |
| ZOOM | Fixed |
| B.F.L. | 6.2mm |
| IR | Corrected |
