S08012504020F67
1/2.5″ 8mm low distortion lens, F2.0 high resolution 5-Megapixel M12/S-mount HD lens, IP67 Waterproof Automotive Lens.
S08012504020F67 is 1/2.5″ 8mm low distortion lens for car, F2.0 high resolution 5-Megapixel M12/S-mount HD lens, IP67 Waterproof Automotive Lens.
| IMAGE FORMAT | 1/2.5“ |
| FOCAL LENGTH | 8mm |
| F.O.V. | 50°(D) |
| 40°(H) | |
| 30°(V) | |
| RESOLUTION | 5 MP |
| DISTORTION | <-9% |
| APERTURE | F2.0 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.2m |
| T.T.L. | 24mm |
| STRUCTURE | 6G+IRCF |
| WATERPROOF | IP67 |
