Industrial Lens – C1201014M5

C1201014M5 is C-Mount 12.5mm 5-Megapixel Manual FA Industrial Lens, F1.4~16 aperture, Low distortion lens, suitable for low-light conditions.

1″ 12.5mm F1.4 5MP C-Mount Industrial Lens

This 1″ 12.5mm C-Mount Industrial lens is designed for 5MP industrial cameras and automated inspection systems requiring a balanced combination of resolution, brightness, and geometric accuracy. With a fast F1.4 aperture, <1.6% TV distortion, and 66° diagonal FOV, it provides reliable imaging for factory automation, dimensional inspection, robotics, and industrial vision applications.

C-Mount Industrial Lens Highlights

• 1″ sensor compatibility for industrial cameras requiring a relatively large image format.
• 5MP resolution supports detailed inspection and machine vision imaging.
• F1.4–16 aperture range provides high light-gathering capability and flexible exposure control.
• <1.6% TV distortion helps maintain accurate representation of object geometry.
• C-Mount interface supports integration with a wide range of industrial and machine vision cameras.
• M46 × 0.75 filter thread allows compatible optical filters to be integrated into the imaging system.

C-Mount Industrial Lens Applications

Precision Industrial Inspection

The 12.5mm focal length provides a practical field of view for inspection systems that need to capture a defined working area without using an extremely wide-angle lens. With 66° diagonal, 55° horizontal, and 42° vertical FOV on a 1″ format, the lens can cover a useful inspection area while maintaining a relatively controlled perspective.

The <1.6% TV distortion specification is particularly useful when the captured image is used for dimensional comparison, edge detection, component positioning, or visual measurement. Lower geometric distortion can help reduce image deformation when straight edges, circular components, or other dimensional features need to be analyzed.

Factory Automation & Machine Vision

The F1.4 maximum aperture provides strong light-gathering capability for machine vision systems operating with short exposure times or limited illumination. The adjustable F1.4–16 aperture also allows system integrators to balance brightness and depth of field according to the inspection requirement.

For automated production lines, this lens can be paired with 5MP industrial cameras for applications such as component inspection, product positioning, surface inspection, assembly verification, and dimensional checking.

For selecting the appropriate sensor and lens combination, the Sensor Guide can help engineers evaluate image format compatibility, while the Lens Selection Guide provides additional guidance for matching focal length, sensor size, and application requirements.

Robotics and Automated Equipment

The 12.5mm focal length and manual optical adjustments make this lens suitable for fixed-camera installations on robotic workstations and automated equipment. It can be used for object detection, part localization, assembly verification, and visual guidance where consistent image geometry is important.

For robotic vision systems requiring different working distances or fields of view, TOWIN’s Robotics Vision solutions provide additional application references.

Compatible Device List

• 1″ industrial cameras
• 5MP machine vision cameras
• C-Mount industrial cameras
• Factory automation inspection cameras
• Robotic vision systems
• Automated optical inspection equipment
• Component inspection systems
• Dimensional and positioning vision systems

Designed for machine vision inspection, factory automation, robotic vision, and industrial imaging applications.

Frequently Asked Questions

Q: What camera sensor size is this 12.5mm lens designed for?
A: This lens is designed for a 1″ image format and is suitable for industrial cameras using a compatible 1″ sensor.

Q: What is the resolution of this C-Mount lens?
A: The lens is specified for 5MP resolution, making it suitable for many 5MP industrial and machine vision cameras.

Q: What is the field of view of the 12.5mm lens?
A: The specified FOV is 66° diagonal, 55° horizontal, and 42° vertical for the 1″ image format.

Q: Is this lens suitable for machine vision inspection?
A: Yes. Its 5MP resolution, C-Mount interface, F1.4 aperture, and <1.6% TV distortion make it suitable for a range of automated inspection and machine vision applications.

Q: What is the advantage of the F1.4 aperture?
A: F1.4 provides high light-gathering capability, which can be useful for short exposure times, high-speed imaging, or machine vision systems operating under limited illumination.

Q: Can the aperture be adjusted?
A: Yes. The manual iris provides an aperture range from F1.4 to F16, allowing users to adjust image brightness and depth of field.

Q: Does this lens have low distortion?
A: The specified TV distortion is below 1.6%. This provides relatively controlled geometric distortion and can be beneficial for inspection tasks involving edges, shapes, and dimensional features.

Q: What type of camera mount does this lens use?
A: It uses a standard C-Mount interface and is intended for compatible C-Mount industrial cameras.
