CCL14025MPF
Low distortion wide angle 2.5mm 72° M7 mount lens 1/4″ HD 1.3MP for CCTV IP camera
CCL14025MPF Low distortion wide angle 2.5mm 72° M7 mount lens 1/4″ HD 1.3MP for CCTV IP camera
| IMAGE FORMAT | 1/4″ |
| FOCAL LENGTH | 2.5mm |
| F.O.V. | 85°(D) |
| 72°(H) | |
| 50°(V) | |
| RESOLUTION | 2 MP |
| TV DISTORTION | <1% |
| APERTURE | F2.4 |
| MOUNT | M7x0.35 |
| IRIS | Fixed |
| M.O.D. | 0.1m |
| T.T.L. | 15.04mm |
| DIMENSION | Φ12×11.05mm |
| LENS COMPOMEMT | 2G2P+IR cut |
CCL14025MPF Low distortion wide angle 2.5mm 72° M7 mount lens HD 1.3MP for CCTV IP camera
