CCL13042MP
Low distortion wide angle 4.2mm M8 mount lens HD megapixel rectilinear scanning
CCL13042MP Low distortion wide angle 4.2mm M8 mount lens HD megapixel rectilinear scanning
| IMAGE FORMAT | 1/3″ |
| FOCAL LENGTH | 4.2mm |
| F.O.V. | 68°(D) |
| 60°(H) | |
| 46°(V) | |
| RESOLUTION | Megapixel |
| DISTORTION | <1% |
| APERTURE | F2.4 |
| MOUNT | M8X0.5 |
| IRIS | Fixed |
| FOCUS | Manual |
| ZOOM | Fixed |
| T.T.L. | 7.09mm |
| LENS COMPOMEMT | 1G4P |
CCL13042MP Low distortion wide angle 4.2mm M8 mount lens HD megapixel rectilinear scanning
