Low distortion wide angle 3.4mm 85° M12 mount lens 1/2.3“ with HD 18MP UAV drone
CCL123034MPFR Low distortion wide angle 3.4mm 85° M12 mount lens 1/2.3“ with HD 18MP UAV drone
| IMAGE FORMAT | 1/2.3“ |
| FOCAL LENGTH | 3.4mm |
| F.O.V. | 98°(D) |
| 85°(H) | |
| 68.8°(V) | |
| RESOLUTION | 18 MP |
| DISTORTION | <2% |
| APERTURE | F2.8 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| M.O.D. | 0.4m |
| T.T.L. | 25mm |
| R. I. | >70% |
| LENS BARREL | PC+30%GF |
| COMPOMEMT | 5G2ASP+IRcut |
CCL123034MPFR Low distortion wide angle 3.4mm 85° M12 mount lens with HD 18MP UAV drone
