Low distortion 9.5mm 40° M12 mount lens 1/1.8″ with HD 3MP rectilinear scanning
CCL118095MPFR Low distortion 9.5mm 40° M12 mount lens 1/1.8″ with HD 3MP rectilinear scanning
| IMAGE FORMAT | 1/1.8″ |
| FOCAL LENGTH | 9.5mm |
| D.F.O.V. | 52° |
| H.F.O.V. | 40° |
| RESOLUTION | 3 MP |
| DISTORTION | <-2% |
| APERTURE | F2.8 |
| MOUNT | M12x0.5 |
| IRIS | Fixed |
| B.F.L. | 3.34mm |
| T.T.L. | 12.87mm |
| BARREL | Plastic |
| LENS COMPOMEMT | 2G2P+IR cut |
CCL118095MPFR Low distortion 9.5mm 40° M12 mount lens with HD 3MP rectilinear scanning
Online contact
| SENSOR | |
|---|---|
| E.F.L. | |
| H. F.O.V. | |
| FNo. | |
| Max Dist. | |
| IRIS | |
| MOUNT | |
| RESOLUTION | |
| T.T.L.(mm) | |
| FEATURE | |
| MARK |
