CCL118085MPF
Low distortion 8.5mm 43° M12 mount lens 1/1.8″ with HD 6MP rectilinear scanning
CCL118085MPF Low distortion 8.5mm 43° M12 mount lens 1/1.8″ with HD 6MP rectilinear scanning
| IMAGE FORMAT | 1/1.8″ |
| FOCAL LENGTH | 8.5mm |
| D.F.O.V. | 60° |
| H.F.O.V. | 43° |
| RESOLUTION | 5 MP |
| DISTORTION | <-1.15% |
| APERTURE | F3.0 |
| MOUNT | M12X0.5 |
| IRIS | Fixed |
| M.O.D. | 0.2m |
| B.F.L. | 2.79mm |
| TTL | 11.95 |
| CONSTRUCTION | 5G+IRF |
CCL118085MPF Low distortion 8.5mm 43° M12 mount lens with HD 6MP rectilinear scanning
