C2511014M12IR – 1
C-Mount 1/1.2″ 25mm low-distortion lens, manual iris and focus, F1.4, 8 Megapixel CCTV lens, IR-corrected.
C2511014M12IR – 1 is C-Mount 1/1.2″ 25mm low-distortion lens, manual iris and focus, F1.4, high resolution 8 Megapixel CCTV lens, IR-corrected.
| IMAGE FORMAT | Max Φ17.6mm |
| SENSOR SIZE | 1/1.2″ |
| FOCAL LENGTH | 25mm |
| F.O.V. | 29.2°(D) |
| 25.5°(H) | |
| 14.6°(V) | |
| RESOLUTION | 8 MP |
| DISTORTION | <-1.5% |
| APERTURE | F1.4 |
| MOUNT | C-Mount |
| IRIS | Manual |
| FOCUS | Manual |
| M.O.D. | 1.5m |
| IR | Corrected |
